Our balloon lights in high presssure sodium lamp is made for large industrial site area illumination for their features of glare free, 360degree illumination, high light efficacy (LED), quick and easy setup, portability and easy to carry etc.
Large industrial area and site use our balloon light for a temporary work site lighting for conveninent 360degree effficient glare free illumination.
HPS - high pressure sodium lamp is featured for its warm bright color temperature around 2200k. Also metal halde lamp is available.
It highlights safety, bright, energy efficient, durable and portable features that put plant or site maintenance staff with quick response, efficiency and more safety, convenience.
It is taken as temporary lighting or emergancy lighting at site in most industrial cases.
Important features of our glare free balloon lights?
1) No-glare - It fulfill glare free feature by our patented special treated fabric envelope in tubular or ellipse shape.
2) Less eye fatigue - Our balloon lights or inflatable light tower cast very soft lght in human eyes which makes it felt comfortable and no tensioned feeling at all.
3) Large area illumination - It could cover a illuminated area of over 20,000 square meter. besides, our HMI lighting balloons has a very similar color temperature around 6000k, Moreover, flicker free electronic is available for a even better light quality.
4) High portability - the Sun series balloon light and columus inflatable light tower has portable range with compact packing option in Pelican type air-tight portable plastic case of IP67 or IP68. LED drives or ballast gears are compact to deploy and connect to make it work. Further, a cylindrical cased version of packing is available at special request.
As an important lighting type for the industries as non-glare option, especially in
-
oil & gas,
-
power plant maintenance,
-
power grid or cable line maintenance,
-
industrial area,
-
railway,
-
mining outdoor site,
-
heavy industrial manufacturing locations etc.
GENERAL FEATURES
1) Air-inflated balloon structure with special fabric, with or without internal reflector; Kelvar material or PTFE material is optional for envelope for much more endurable use
2) Primarily for tripod stand mount, backpack, pole mount, equipment mount etc .application
3) Indoor or outdoor use
4) Different efficienct light source available - Tungsten (HA), LED, HID (HMI / metal halide)
5) Perfectly compatible to global electrical power in AC110, 120, 220, 230V etc. DC power version for some models.
6) Start and work directly - tungsten or with electrical ballast (HID)or drive (LED). A battery work mode is available at its
3 standard ranges: Sun portable - 80w~400w. dia. 45cm~90m x H30~60cm; Sun standard - dia. 60cm~110m x H45~90cm. Sun Ex - 2,000w~4,800w. dia. 90cm~130m x H60~110cm.
AC power work mode. Mainly for event or large area (>5,000sqm) illumination
Classified into below categories on light source:
- Tungsten halogen - 650~4,000w;
- LED (white 3000k/6500k optional) - 60w~600w; custom 800w~1,200w;
- HMI (quick hot-restrike) - 575w~4,800w; (>1000w is not for portable use)
- MH (metal halide) - 150w~4,000w;
FUNCTIONS
1) lighting/illumination 2) signal 3) communication
APPLICATIONS
Our lighting balloons and inflatable light tower could be widely used for a list of industries not limited to industrial places
Places that our balloon lights could be used (not limited to industrial application)
3. Highway or newly built road
4. Airport, railway, station site etc.
5. Forensic spot
6. Underway, cave etc.
7. Warehouse
11. Flagger station
12. Event site
13. Drill, training and maneuver locations
14. Farms
Themes that our balloon lights could be related with or involved in for industrial purpose
- Maintenance
- Manufacturing
- Logistic and storage
- Engineering
- Construction
- Safety patrol & check
- Exploration and field research
- Outdoor sampling
- Miscellaneous
========================
HAFE Sun
========================
Balloon lights in high pressure sodium lamp for large area illumination
Superior advantages against conventional light tower or work light units:
1) 360deg. illumination without blind point, shadow free or light shadow (traditional light towers only cast directional light beam)
2) glare-free illumination - especially for construction at night time - less eye-fatigue, more safer and productivity
3) LED or HMI or metal halide or tungsten halogen light source optional.
4) longevity, upto 3-5 years with proper maintenance
5) Water resistant - rain proof (up to medium load)
6) Dust proof - IP54, windproof upto 80km/h in strengthened version
7) customisable adaptor to your current light tower pole for easy installation
8) Quick setup (< 7 min.), plug-and-play
9) Much more lighter weight than traditional light towers
10) Autonomous self-inflation, with built-in pressure sensor control,safe protection
11) Remote control(On/Off), LED dimmable(10-100%) functions could be integrated
| HAFE Sun™ BALLOON Metal Halide LIGHT SERIES |
| Model No |
INDUSTRY |
LAMP TYPE |
DESCRIPTION |
| Sun140M |
Industry |
Metal Halide |
Sun™ balloon light,160cm Diameter-4.2m Tripod telescopic stand,140W(euro) |
| Sun300M |
Industry |
Metal Halide |
Sun™ balloon light,100cm Diameter-4.2m Tripod telescopic stand,300W(euro) |
| Sun600M |
Industry |
Metal Halide |
Sun™ balloon light,130cm Diameter-4.2m Tripod telescopic stand,600W(euro) |
| Sun250M |
industry |
Metal Halide |
Sun™ balloon light,160cm Diameter-4.2m Tripod telescopic stand,250W |
| Sun400M |
industry |
Metal Halide |
Sun™ balloon light,100cm Diameter-4.2m Tripod telescopic stand,400W |
| Sun1000M |
industry |
Metal Halide |
Sun™ balloon light,130cm Diameter-4.2m Tripod telescopic stand,1000W |
| Sun2000M |
industry |
Metal Halide |
Sun™ balloon light,160cm Diameter-4.2m Tripod telescopic stand,2000W |
| Sun3000M |
industry |
Metal Halide |
Sun™ balloon light,160cm Diameter-4.2m Tripod telescopic stand,3000W |
| Sun4000M |
industry |
Metal Halide |
Sun™ balloon light,160cm Diameter-4.2m Tripod telescopic stand,4000W |
| Sun140DM |
industry |
Metal Halide |
Sun™ balloon light,100cm Diameter-4.2m Tripod telescopic stand,140WDC |
| Sun300DM |
industry |
Metal Halide |
Sun™ balloon light,100cm Diameter-4.2m Tripod telescopic stand,300WDC |
| Sun600DM |
industry |
Metal Halide |
Sun™ balloon light,100cm Diameter-4.2m Tripod telescopic stand,600WDC |
When you are responsible for managing projects like major road construction, emergency responses, large-scale community events or traffic checkpoints, you need bright, glare-free and reliable light that is capable of maintaining its integrity regardless of the conditions at hand.
Our LED balloon lights are capable of shedding large amounts of light over a full 360-degree range. On top, unlike other common options (such as conventional light towers or simple work lamps), you do not have to deal with potentially dangerous side effects like glare, shadows, or dark spots.On top LED Balloon lights offer instant ON – Off technology with no need for a cool down time. Pack them up right away after usage!
Sun LED are bright, reliable (LED ‘Bulbs’ hold up to 50.000 hours) and very energy efficient. In fact, 3 LED balloon lights can run on one small Honda generator, and a battery powered unit can operate easily in between 6-12 hours on one battery.
/////heavy duty construction
Heavy construction such as highway work, paving, bridge building, or even the construction of high rises more and more take place at night to avoid heavy traffic and congestion, to work safer and more efficient, to fulfill deadlines, or to simply finish before bad weather sets in.
