Sphere LED 3000W Hmi Balloon Lights With International Electronic Ballasts

Basic Information
Place of Origin: CHINA
Brand Name: HAFE
Certification: CE
Model Number: Artemis
Minimum Order Quantity: 1 unit
Price: Negotiation
Packaging Details: Carton and Hicase packing
Delivery Time: 10-15working days
Payment Terms: T/T, L/C
Supply Ability: 3000units /year
Detail Information
MAX Watt: LED3000W Color Tempereture: 2600k-5600k
Option: 6.5 Diameter Can Be With LED 7200W Ballasts: Can Use ARRI Ballasts Or Hafe Ballasts
LED 1440W: LED 1440W (480w/2600k + 960w/5600k Dimmable) (158 400lm) LED 2880W: LED 2880W (960w/2600k + 1920w/5600k Dimmable) (316 800lm)
LED 4320W: LED 4320W (1440w/2600k + 2880w/5600k Dimmable) (475 200lm) LED 7200W: LED 7200W (2880w/2600k + 4320w/5600k Dimmable) (792 000lm)
High Light:

3000W led hmi balloon lights

,

Sphere LED Hmi Balloon Lights


Product Description

Sphere Type LED Film lighting Compatible With International Brand Electronic Ballasts





The lighting balloons are widely used in set lighting (fill or main) as a high quality softened light source with its high pwer high output and unmatchable performance. The lighting balloons are able to create amazing lighting that a conventional lighting could unsatisfactorily to deliver.


At a location where rigging is not possible or practical, a large area of diffused man-made soft light needed, lighting balloons may be a better choice.


The name of lighting balloons are "Artemis".Wuxi Fenigal & Science and Technology has an independent R&D process for the material, balloon fdesign and abrications.


And we started these lighting balloons for film and tv industy from 2017. And we hope our lighting balloons could bring you joys and successes.

Daylight ranges are compatible with international brand electronic ballasts. Economic flicke-free EBs are also available.



Our daylight range lighting balloons are built in such a way that they could work with your Arri electronic ballasts to form a set light wanted. Our veam connector receptable box gives it a convenience for different comnbinations of power.



EB pictures at the courtesy of ARR:575/1200W 1200/1800W 2.5/4kW


POWER GEMS Also compatible to Power Gems electronic ballast from 575 till 4000w



Sphere - Ellipse: HMI
Unit Shape Lamps / Socket Dims Max Height Helium Techs Set Up Time Cable Length Max Wind Speed
tanks
(291 cft)
1,150 W HMI Sphere | Ellipse 2x 575 W / G22 6.5’ | 6.5’x8’ 35’ 1 1 30 min 45’ 10 mph

2.4 KW HMI Sphere | Ellipse 2x 1.2 KW / G38 8’ | 8’x10’ 35’ 2 1 35 min 55’ 15 mph

2.4 KW HMI Sphere | Ellipse 2x 1.2 KW / G38 10’ | 10’x12’ 45’ 3 1 35 min 55’ 15 mph

4.8 KW HMI Sphere | Ellipse 4x 1.2 KW / G38 12’ | 12’x14’ 65’ 5 1 45 min 100’ 20 mph

5 KW HMI Ellipse 2x 2.5 KW / G38 14’x16’ 75’ 8 2 60 min 100’ 25 mph

8 KW HMI Ellipse 2x 4 KW / G38 14’x16’ 75’ 8 2 60 min 100’ 25 mph

10 KW HMI Sphere 4x 2.5 KW / G38 16’5 80’ 10 2 75 min 100’ 25 mph

16 KW HMI Sphere 4x 4 KW / G38 16’5 80’ 10 2 75 min 100’ 25 mph


ACCESSORIES:
Skirts
Reflectors

Sphere - Ellipse: Tungsten
Unit Shape Lamps / Socket Dims Max Height Helium Techs Set Up Time Cable Length Max Wind Speed
tanks
(291 cft)
4 KW Tungsten Sphere | Ellipse 4x 1 KW / G6.35 6.5’ | 6’x8’ 40’ 1 1 30 min 45’ 10 mph

4 KW Tungsten Sphere | Ellipse 4x 1 KW / G6.35 8’ | 8’x10’ 45’ 2 1 30 min 45’ 15 mph

5 KW Tungsten Sphere | Ellipse 2x 2.5 KW / G38 8’ | 8’x10’ 40’ 2 1 30 min 45’ 15 mph

5 KW Tungsten Sphere | Ellipse 2x 2.5 KW / G38 10’ | 10’x12’ 45’ 3 1 30 min 45’ 15 mph

8 KW Tungsten Sphere | Ellipse 8x 1 KW / G6.35 12’ | 12’x16’ 70’ 5 1 50 min 100’ 20 mph

10 KW Tungsten Sphere | Ellipse 2x 5 KW / G38 12’ | 12’x16’ 70’ 5 1 50 min 100’ 20 mph

15 KW Tungsten Sphere | Ellipse 2x 5 KW 16’5 80’ 10 2 70 min 120’ 25 mph
+ 2x 2.5 KW / G38
20 KW Tungsten Sphere | Ellipse 4x 5 KW / G38 16’5 80’ 10 2 70 min 120’ 25 mph



Sphere - Ellipse: Hybrid
Unit Shape Lamps / Socket Dims Max Height Helium Techs Set Up Time Cable Length Max Wind Speed
tanks
(291 cft)
3.7 KW Sphere | Ellipse 1x 2.5 KW 8’ | 8’x10’ 35’ 2 1 40 min 45’ 15 mph
Hybrid + 1x 1.2 KW G38
3.7 KW Sphere | Ellipse 1x 2.5 KW 10’ | 10’x12’ 45’ 3 1 40 min 45’ 15 mph
Hybrid + 1x 1.2 KW G38
7.4 KW Sphere | Ellipse 2x 2.5 KW 12’ | 12’x14’ 60’ 5 1 55 min 100’ 20 mph
Hybrid + 2x 1.2 KW G38
8.4 KW Ellipse 6x 1 KW 8.8’x12’ 40’ 4 1 40 min 55’ 15 mph
Hybrid + 2 x 1.2 KW G6.35 + G38
9.6 KW Ellipse 6x 1 KW 12’x14’ 50’ 5 1 55 min 100’ 20 mph
Hybrid + 3x 1.2 KW G6.35 + G38
18 KW Ellipse 6x 1 KW 14’ x 20.6’ 80’ 12 2 75 min 100’ 20 mph
Hybrid + 3x 4 KW G6.35 + G38
18 KW Sphere 2x 5 KW 16.5’ 80’ 10 2 75 min 100’ 20 mph
Hybrid + 2x 4 KW G38
19 KW Ellipse 6x 1 KW 14’ x 20.6’ 80’ 12 2 75 min 100’ 20 mph
Hybrid + 1x 5 KW
  + 2x 4 KW /
  G6.35 + G38
20 KW Ellipse 8x 1 KW 14’ x 20.6’ 80’ 12 2 75 min 100’ 20 mph
Hybrid + 3x 4 KW
  G6.35 + G38


Sphere - Ellipse: Sodium / Mercury
Unit Shape Lamps / Socket Dims Max Height Helium Techs Set Up Time Cable Length Max Wind Speed
tanks
(291 cft)
4 KW Sphere 4x 1 KW / 14’ 60’ 5 1 65 min 100’ 15 mph
Sodium / Mercury Mogul E39



Sphere LED 3000W Hmi Balloon Lights With International Electronic Ballasts 0Sphere LED 3000W Hmi Balloon Lights With International Electronic Ballasts 1
