| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HAFE |
| Certification: | CE |
| Model Number: | Artemis |
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiation |
| Packaging Details: | Carton and Hicase packing |
| Delivery Time: | 10-15working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 3000units /year |
| MAX Power: | LED 1200W~1800W | Color: | RGBW |
|---|---|---|---|
| Approx. Max. Output: | 79,000lm | Ballasts: | Can Use ARRI Ballasts Or Hafe Ballasts |
| DMX: | DMX512 Control Feature | Helilum: | 15m3 Helilum Needed |
| High Light: | Photography HMI Balloon Light,PRO 1800W HMI Balloon Light,Video Camera Studio HMI Balloon Light |
||
The lighting balloons are widely used in set lighting (fill or main) as a high quality softened light source with its high pwer high output and unmatchable performance. The lighting balloons are able to create amazing lighting that a conventional lighting could unsatisfactorily to deliver.
lighting data
Light source newest generation LED
Colour temperature from 2,700 K to 6,500 K
Average efficiency at 4,400 K 93 lm/W
Nominal power 850 W/1000WLED
Regulation type constant current
Diffusion angle 120° (chart 1.)
CRI - colour rendering index > 95 (chart 2.)
Flicker free 31 kHz
Potentiometer - colour temperature – intensity
Set up time 15 min
Inflation type external pump *
power supply Max. entry power 1000 W
Balloon to power supply cable length 10 m I 30 ft
Connector to power supply cable length 2 m I 6 ft
Noise level (remote power supply) 23 dB
Input voltage 90-260 V AC
Input frequency 50-60 Hz
Output voltage 48 V DC
Temperature range for optimal use -5°C / +40°C
dimensions and packaging
Balloon shape sphere
Balloon dimensions 160 cm I 5 ft in diameter
Weight of the balloon 12 kg I 27 lbs
| Sphere - Ellipse: HMI | |||||||||
| Unit | Shape | Lamps / Socket | Dims | Max Height | Helium | Techs | Set Up Time | Cable Length | Max Wind Speed |
| tanks | |||||||||
| (291 cft) | |||||||||
| 1,150 W HMI | Sphere | Ellipse | 2x 575 W / G22 | 6.5’ | 6.5’x8’ | 35’ | 1 | 1 | 30 min | 45’ | 10 mph |
| 2.4 KW HMI | Sphere | Ellipse | 2x 1.2 KW / G38 | 8’ | 8’x10’ | 35’ | 2 | 1 | 35 min | 55’ | 15 mph |
| 2.4 KW HMI | Sphere | Ellipse | 2x 1.2 KW / G38 | 10’ | 10’x12’ | 45’ | 3 | 1 | 35 min | 55’ | 15 mph |
| 4.8 KW HMI | Sphere | Ellipse | 4x 1.2 KW / G38 | 12’ | 12’x14’ | 65’ | 5 | 1 | 45 min | 100’ | 20 mph |
| 5 KW HMI | Ellipse | 2x 2.5 KW / G38 | 14’x16’ | 75’ | 8 | 2 | 60 min | 100’ | 25 mph |
| 8 KW HMI | Ellipse | 2x 4 KW / G38 | 14’x16’ | 75’ | 8 | 2 | 60 min | 100’ | 25 mph |
| 10 KW HMI | Sphere | 4x 2.5 KW / G38 | 16’5 | 80’ | 10 | 2 | 75 min | 100’ | 25 mph |
| 16 KW HMI | Sphere | 4x 4 KW / G38 | 16’5 | 80’ | 10 | 2 | 75 min | 100’ | 25 mph |
| ACCESSORIES: | |||||||||
| Skirts | |||||||||
| Reflectors | |||||||||
| Sphere - Ellipse: Tungsten | |||||||||
| Unit | Shape | Lamps / Socket | Dims | Max Height | Helium | Techs | Set Up Time | Cable Length | Max Wind Speed |
| tanks | |||||||||
| (291 cft) | |||||||||
| 4 KW Tungsten | Sphere | Ellipse | 4x 1 KW / G6.35 | 6.5’ | 6’x8’ | 40’ | 1 | 1 | 30 min | 45’ | 10 mph |
| 4 KW Tungsten | Sphere | Ellipse | 4x 1 KW / G6.35 | 8’ | 8’x10’ | 45’ | 2 | 1 | 30 min | 45’ | 15 mph |
| 5 KW Tungsten | Sphere | Ellipse | 2x 2.5 KW / G38 | 8’ | 8’x10’ | 40’ | 2 | 1 | 30 min | 45’ | 15 mph |
| 5 KW Tungsten | Sphere | Ellipse | 2x 2.5 KW / G38 | 10’ | 10’x12’ | 45’ | 3 | 1 | 30 min | 45’ | 15 mph |
| 8 KW Tungsten | Sphere | Ellipse | 8x 1 KW / G6.35 | 12’ | 12’x16’ | 70’ | 5 | 1 | 50 min | 100’ | 20 mph |
| 10 KW Tungsten | Sphere | Ellipse | 2x 5 KW / G38 | 12’ | 12’x16’ | 70’ | 5 | 1 | 50 min | 100’ | 20 mph |
| 15 KW Tungsten | Sphere | Ellipse | 2x 5 KW | 16’5 | 80’ | 10 | 2 | 70 min | 120’ | 25 mph |
| + 2x 2.5 KW / G38 | |||||||||
| 20 KW Tungsten | Sphere | Ellipse | 4x 5 KW / G38 | 16’5 | 80’ | 10 | 2 | 70 min | 120’ | 25 mph |
| Sphere - Ellipse: Hybrid | |||||||||
| Unit | Shape | Lamps / Socket | Dims | Max Height | Helium | Techs | Set Up Time | Cable Length | Max Wind Speed |
| tanks | |||||||||
| (291 cft) | |||||||||
| 3.7 KW | Sphere | Ellipse | 1x 2.5 KW | 8’ | 8’x10’ | 35’ | 2 | 1 | 40 min | 45’ | 15 mph |
| Hybrid | + 1x 1.2 KW G38 | ||||||||
| 3.7 KW | Sphere | Ellipse | 1x 2.5 KW | 10’ | 10’x12’ | 45’ | 3 | 1 | 40 min | 45’ | 15 mph |
| Hybrid | + 1x 1.2 KW G38 | ||||||||
| 7.4 KW | Sphere | Ellipse | 2x 2.5 KW | 12’ | 12’x14’ | 60’ | 5 | 1 | 55 min | 100’ | 20 mph |
| Hybrid | + 2x 1.2 KW G38 | ||||||||
| 8.4 KW | Ellipse | 6x 1 KW | 8.8’x12’ | 40’ | 4 | 1 | 40 min | 55’ | 15 mph |
| Hybrid | + 2 x 1.2 KW G6.35 + G38 | ||||||||
| 9.6 KW | Ellipse | 6x 1 KW | 12’x14’ | 50’ | 5 | 1 | 55 min | 100’ | 20 mph |
| Hybrid | + 3x 1.2 KW G6.35 + G38 | ||||||||
| 18 KW | Ellipse | 6x 1 KW | 14’ x 20.6’ | 80’ | 12 | 2 | 75 min | 100’ | 20 mph |
| Hybrid | + 3x 4 KW G6.35 + G38 | ||||||||
| 18 KW | Sphere | 2x 5 KW | 16.5’ | 80’ | 10 | 2 | 75 min | 100’ | 20 mph |
| Hybrid | + 2x 4 KW G38 | ||||||||
| 19 KW | Ellipse | 6x 1 KW | 14’ x 20.6’ | 80’ | 12 | 2 | 75 min | 100’ | 20 mph |
| Hybrid | + 1x 5 KW | ||||||||
| + 2x 4 KW / | |||||||||
| G6.35 + G38 | |||||||||
| 20 KW | Ellipse | 8x 1 KW | 14’ x 20.6’ | 80’ | 12 | 2 | 75 min | 100’ | 20 mph |
| Hybrid | + 3x 4 KW | ||||||||
| G6.35 + G38 | |||||||||
| Sphere - Ellipse: Sodium / Mercury | |||||||||
| Unit | Shape | Lamps / Socket | Dims | Max Height | Helium | Techs | Set Up Time | Cable Length | Max Wind Speed |
| tanks | |||||||||
| (291 cft) | |||||||||
| 4 KW | Sphere | 4x 1 KW / | 14’ | 60’ | 5 | 1 | 65 min | 100’ | 15 mph |
| Sodium / Mercury | Mogul E39 | ||||||||
