Lamp Source: | LED Lamp | Color: | Cold And Warm White |
---|---|---|---|
Function: | Lighting For Fime Event Scene | Ballast: | Arri Or Hafe Ballast |
Helium: | 16CBM | Style: | Smart Film Lighting |
Shape: | Cube Or Customized | ||
High Light: | 16cbm Helium Film Lighting Balloon,White Cube Shaped Film Lighting Balloon,Dimmable Event Film Lighting Balloon |
Dimmable or Random White Cube 16cbm Helium Film Lighting Balloon For Event Scene
The name of lighting balloons are "Artemis".Wuxi Fenigal & Science and Technology has an independent R&D process for the material, balloon design and abrications.
And we started these lighting balloons for film and tv industy from 2017. And we hope our lighting balloons could bring you joys and successes.
Daylight ranges are compatible with international brand electronic ballasts. Economic flicke-free EBs are also available.
GENERAL FEATURES
1) air-tight structural design with special treated fabric envelope material
2) lighter-than-air materials make it possible for helium filling for float overhead application
3) friendly to air-filling for hanging on rigging or tripod mount application
4) indoor or outdoor; water-proof, weather-proof;
Sphere - Ellipse: HMI | |||||||||
Unit | Shape | Lamps / Socket | Dims | Max Height | Helium | Techs | Set Up Time | Cable Length | Max Wind Speed |
tanks | |||||||||
(291 cft) | |||||||||
1,150 W HMI | Sphere | Ellipse | 2x 575 W / G22 | 6.5’ | 6.5’x8’ | 35’ | 1 | 1 | 30 min | 45’ | 10 mph |
2.4 KW HMI | Sphere | Ellipse | 2x 1.2 KW / G38 | 8’ | 8’x10’ | 35’ | 2 | 1 | 35 min | 55’ | 15 mph |
2.4 KW HMI | Sphere | Ellipse | 2x 1.2 KW / G38 | 10’ | 10’x12’ | 45’ | 3 | 1 | 35 min | 55’ | 15 mph |
4.8 KW HMI | Sphere | Ellipse | 4x 1.2 KW / G38 | 12’ | 12’x14’ | 65’ | 5 | 1 | 45 min | 100’ | 20 mph |
5 KW HMI | Ellipse | 2x 2.5 KW / G38 | 14’x16’ | 75’ | 8 | 2 | 60 min | 100’ | 25 mph |
8 KW HMI | Ellipse | 2x 4 KW / G38 | 14’x16’ | 75’ | 8 | 2 | 60 min | 100’ | 25 mph |
10 KW HMI | Sphere | 4x 2.5 KW / G38 | 16’5 | 80’ | 10 | 2 | 75 min | 100’ | 25 mph |
16 KW HMI | Sphere | 4x 4 KW / G38 | 16’5 | 80’ | 10 | 2 | 75 min | 100’ | 25 mph |
ACCESSORIES: | Skirts | Reflectors | |||||||
Sphere - Ellipse: Tungsten | |||||||||
Unit | Shape | Lamps / Socket | Dims | Max Height | Helium | Techs | Set Up Time | Cable Length | Max Wind Speed |
tanks | |||||||||
(291 cft) | |||||||||
4 KW Tungsten | Sphere | Ellipse | 4x 1 KW / G6.35 | 6.5’ | 6’x8’ | 40’ | 1 | 1 | 30 min | 45’ | 10 mph |
4 KW Tungsten | Sphere | Ellipse | 4x 1 KW / G6.35 | 8’ | 8’x10’ | 45’ | 2 | 1 | 30 min | 45’ | 15 mph |
5 KW Tungsten | Sphere | Ellipse | 2x 2.5 KW / G38 | 8’ | 8’x10’ | 40’ | 2 | 1 | 30 min | 45’ | 15 mph |
5 KW Tungsten | Sphere | Ellipse | 2x 2.5 KW / G38 | 10’ | 10’x12’ | 45’ | 3 | 1 | 30 min | 45’ | 15 mph |
8 KW Tungsten | Sphere | Ellipse | 8x 1 KW / G6.35 | 12’ | 12’x16’ | 70’ | 5 | 1 | 50 min | 100’ | 20 mph |
10 KW Tungsten | Sphere | Ellipse | 2x 5 KW / G38 | 12’ | 12’x16’ | 70’ | 5 | 1 | 50 min | 100’ | 20 mph |
15 KW Tungsten | Sphere | Ellipse | 2x 5 KW | 16’5 | 80’ | 10 | 2 | 70 min | 120’ | 25 mph |
+ 2x 2.5 KW / G38 | |||||||||
20 KW Tungsten | Sphere | Ellipse | 4x 5 KW / G38 | 16’5 | 80’ | 10 | 2 | 70 min | 120’ | 25 mph |
Sphere - Ellipse: Hybrid | |||||||||
Unit | Shape | Lamps / Socket | Dims | Max Height | Helium | Techs | Set Up Time | Cable Length | Max Wind Speed |
tanks | |||||||||
(291 cft) | |||||||||
3.7 KW | Sphere | Ellipse | 1x 2.5 KW | 8’ | 8’x10’ | 35’ | 2 | 1 | 40 min | 45’ | 15 mph |
Hybrid | + 1x 1.2 KW G38 | ||||||||
3.7 KW | Sphere | Ellipse | 1x 2.5 KW | 10’ | 10’x12’ | 45’ | 3 | 1 | 40 min | 45’ | 15 mph |
Hybrid | + 1x 1.2 KW G38 | ||||||||
7.4 KW | Sphere | Ellipse | 2x 2.5 KW | 12’ | 12’x14’ | 60’ | 5 | 1 | 55 min | 100’ | 20 mph |
Hybrid | + 2x 1.2 KW G38 | ||||||||
8.4 KW | Ellipse | 6x 1 KW | 8.8’x12’ | 40’ | 4 | 1 | 40 min | 55’ | 15 mph |
Hybrid | + 2 x 1.2 KW G6.35 + G38 | ||||||||
9.6 KW | Ellipse | 6x 1 KW | 12’x14’ | 50’ | 5 | 1 | 55 min | 100’ | 20 mph |
Hybrid | + 3x 1.2 KW G6.35 + G38 | ||||||||
18 KW | Ellipse | 6x 1 KW | 14’ x 20.6’ | 80’ | 12 | 2 | 75 min | 100’ | 20 mph |
Hybrid | + 3x 4 KW G6.35 + G38 | ||||||||
18 KW | Sphere | 2x 5 KW | 16.5’ | 80’ | 10 | 2 | 75 min | 100’ | 20 mph |
Hybrid | + 2x 4 KW G38 | ||||||||
19 KW | Ellipse | 6x 1 KW | 14’ x 20.6’ | 80’ | 12 | 2 | 75 min | 100’ | 20 mph |
Hybrid | + 1x 5 KW | ||||||||
+ 2x 4 KW / | |||||||||
G6.35 + G38 | |||||||||
20 KW | Ellipse | 8x 1 KW | 14’ x 20.6’ | 80’ | 12 | 2 | 75 min | 100’ | 20 mph |
Hybrid | + 3x 4 KW | ||||||||
G6.35 + G38 | |||||||||
Sphere - Ellipse: Sodium / Mercury | |||||||||
Unit | Shape | Lamps / Socket | Dims | Max Height | Helium | Techs | Set Up Time | Cable Length | Max Wind Speed |
tanks | |||||||||
(291 cft) | |||||||||
4 KW | Sphere | 4x 1 KW / | 14’ | 60’ | 5 | 1 | 65 min | 100’ | 15 mph |
Sodium / Mercury | Mogul E39 |
