High Lumens Electrical Lighting Accessories , Metal Halide Led Replacement Lamps

Basic Information
Place of Origin: China
Brand Name: HAFE
Certification: CE
Model Number: MH50/HED28/U/4K
Minimum Order Quantity: 1unit
Price: Negotiable
Packaging Details: Export Carton Packing
Delivery Time: 5-8Working days
Payment Terms: T/T
Supply Ability: 7-14days
Detail Information
Watts: 50W-1500W Bulb: HED17
Model No: MH50- MH1500 ANSI: M110/E -M57/E
Initial Lumens: 3400 -16600 Lm Mean Lumens: 2200 -12500 Lm
Avg.Life: 10000V/7500H Color: 3200K-4200K
High Light:

pendant light accessories

,

light fitting parts


Product Description

USA and Euro standard Metal Halide Lamp high Lumens 400w Metal Halide led Replacement Lamp



The lamps consist of a small fused quartz or ceramic arc tube which contains the gases and the arc, enclosed inside a larger glass bulb which has a coating to filter out the ultraviolet light produced. They operate at a pressure between 4 and 20 atmospheres, and require special fixtures to operate safely, as well as an electrical ballast. Metal atoms produce most of the light output. They require a warm-up period of several minutes to reach full light output.
Metal-halide lamps are used for general lighting purposes both indoors and outdoors, such as commercial, industrial, and public spaces, parking lots, sports arenas, factories, and retail stores, as well as residential security lighting; automotive and specialty applications are further fields of usage.



Like other gas-discharge lamps such as the very-similar mercury-vapor lamps, metal-halide lamps produce light by ionizing a mixture of gasses in an electric arc. In a metal-halide lamp, the compact arc tube contains a mixture of argon or xenon, mercury, and a variety of metal halides, such as sodium iodide and scandium iodide.



          Lumens
Watts Bulb Item# Description ANSI Initial Mean
          (lm) (lm)
Metal Halide Lamps-Double Ended
70 HT6 1081 MHDE70/UVS/5K M85/E 5000 4000
70 HT6 1045 MHDE70/UVS/3K M85/E 4500 3600
70 HT6 1046 MHDE70/UVS/4K M85/E 5000 4000
100 HT6 1083 MHDE100/UVS/5K M90/E 6500 5500
100 HT6 1082 MHDE100/UVS/3K M90/E 8500 6800
100 HT6 1066 MHDE100/UVS/4K M90/E 8500 6800
150 HT7 1047 MHDE150/UVS/3K M81/E 11000 8800
150 HT7 1048 MHDE150/UVS/4K M81/E 11000 8800
150 HT7 1084 MHDE150/UVS/5K M81/E 11000 8800
250 HT9.5 1085 MHDE250/UVS/4K M80/E 20000 16000
400 HT9.5 1086 MHDE400/UVS/4K M59/E 28000 22400



          Lumens
Watts Bulb Item# Description ANSI Initial Mean
          (lm) (lm)
Metal Halide Lamps- Enclosed Rated
70 HT7.5 1087 MH70/G12/UVS/3K M85/E 5000 4000
70 HT7.5 1049 MH70/G12/UVS/4K M85/E 5600 4480
100 HT7.5 1088 MH100/G12/UVS/3K M90/E 8500 6800
100 HT7.5 1050 MH100/G12/UVS/4K M90/E 8500 6800
150 HT7.5 1089 MH150/G12/UVS/3K M81/E 12500 10000
150 HT7.5 1051 MH150/G12/UVS/4K M81/E 12500 10000

High Lumens Electrical Lighting Accessories , Metal Halide Led Replacement Lamps 0

High Lumens Electrical Lighting Accessories , Metal Halide Led Replacement Lamps 1High Lumens Electrical Lighting Accessories , Metal Halide Led Replacement Lamps 2
