AC120-240V LED DMX512 Lighting Accessories For Lamps And RGBW LED Lighting Use

Basic Information
Place of Origin: China
Brand Name: HAFE
Certification: CE
Model Number: DMX512
Minimum Order Quantity: 1 UNIT
Price: Negotiation
Packaging Details: Hicase Packing or Export Carton Packing
Delivery Time: 7-14days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 3000units/year
Detail Information
Name: DMX512 Power: AC120-240V
Box: Aluminum Box Function: Can Be A Light Show Program
Scenes: Over 1000 Kinds Of Color: 255X255X255
High Light:

pendant light accessories

,

light fitting parts


Product Description



AC120-240V LED DMX512 Electrical Lighting Accessories For RGBW LED Lighting Use



The DMX512 controller is capable of outputting standard DMX512 control signals. Ability to cascade multiple DMX luminaires to match LED DMX drive groups Into a complete DMX control system. In large LED outdoor decoration projects The control system consisting of DMX512 controller and DMX driver is widely used.



General features
There are total 11 sub-menu function "Set Address", "Sound", "Auto", "Strobe", "Fade", "Color", "Channel", "Menu", "Slave", "Temp", "Set Lcd", as shown below. 9 of them has actual use.


8channel selection makes lighting output in 8-ways (namely occupying 8 address points in one DMX universe).



channel-1: master dimming

channel--2: strobe speed

channel-3: 5 types of pre-set light effects (working with channel-4 only)

channel-4: shift speed (working with channel-3 only)

channel-5: Red value setting (1~255)

channel-6: Green value setting (1~255)

channel-7: Blue value setting (1~255)

channel-8: White value setting (1~255)



4channel selection makes lighting output in 4-ways (namely occupying 4 address points in one DMX universe). It is a very easy function.

channel-1: Red value setting (1~255)

channel-2: Green value setting (1~255)

channel-3: Blue value setting (1~255)

channel-4: White value setting (1~255)



Kind remind: you may need to consult to a qualifiedDXM512 lighting technician or good player to have a guidance lead with failure to understand above channel information.Note: channel-3 and channel-4 has priority over othe


Basic Functions

LED technology. Highly power efficient and energy saving Versatily built and customizable. Increadibly long working lifetime (>50,000 hrs).


All-in-1. RGB+W LED chips make it possible to light up or decor the places, rendering adaptable themes wanted by same unit of product.Smart control light show. Thanks to the control box and DMX technology, the unit could render up to 1,000 mixed colors and many possible lighting effects.



DMX console adaptability. The product is 100% adaptable to all types of DMX console gloablly. With pre-set color modes; autonomous mode ot manual setting mode.Flicker free. Friendly to broadcasting occasions.


Specifications


Model DMX512
Input voltage 120V-240V
Max load current 4A
Max output power 800W
Output Scale level 4096 levels
Input signal DMX512/1990
Output DMX Channel  8Channels
Working temperature -30°C-65°C
Dimension L260×W110×H40(mm)
Package Size L270×W130×H45(mm)
Weight (G.W) 920g




AC120-240V LED DMX512 Lighting Accessories For Lamps And RGBW LED Lighting Use 0


AC120-240V LED DMX512 Lighting Accessories For Lamps And RGBW LED Lighting Use 1AC120-240V LED DMX512 Lighting Accessories For Lamps And RGBW LED Lighting Use 2
