Genuine 240W Electrical Lighting Accessories Single Output LED Power Supply IP67

Basic Information
Place of Origin: CHINA
Brand Name: Meanwell
Certification: IP67, PFC, CUL, CE, CB, PSE,TUV
Model Number: HLG-240H-36
Minimum Order Quantity: 1unit
Price: Negotiable
Packaging Details: export packing
Delivery Time: 5-8working days
Payment Terms: T/T, L/C
Supply Ability: 3000units/year
Detail Information
Output Power: 240W Input Voltage: 90~305VAC 127 ~ 431VDC
Output Type: Single Output Voltage: 36V
Output Current: 6.7A Waterproof: IP67
MTBF: 207.9Khrs Min Feature: Built-in Active PFC
Efficiency: High Efficiency Up To 94% Working Temp.Humidity: -40 ~ +80℃, 10 ~ 95% RH
LED Driver Cooling Type: Cooling By Free Air Convection LED Driver's Dimension: 244.2*68*38.8mm 1.3Kg; 12pcs/16.6Kg/0.84CUFT
High Light:

pendant light accessories

,

light fitting parts


Product Description

Genuine MEANWELL 240W Single Output LED Power Supply HLG-240H-36V



MODEL HLG-320H-12 HLG-320H-15 HLG-320H-20 HLG-320H-24

















OUTPUT

DC VOLTAGE 12V 15V 20V 24V
C&C REGION 6 ~12V 7.5 ~ 15V 10 ~ 20V 12 ~ 24V
RATED CURRENT 22A 19A 15A 13.34A
RATED POWER 264W 285W 300W 320.2W
RIPPLE & NOISE 150mVp-p 150mVp-p 150mVp-p 150mVp-p
VOLTAGE ADJ. 10.8~13.5V 13.5~ 17V 17 ~ 22V 22 ~ 27V
CURRENT ADJ.RANGE Can be adjusted by internal potential meter .or through output cable
11 ~ 22A 9.5 ~ 19A 7.5 ~ 15A 6.67~13.34A
VOLTAGE TOLERANCE 2.5% 2.0% 1.0% 1.0%
LINE REGULATION 0.5% 0.5% 0.5% 0.5%
LOAD REGULATION 2.0% 1.5% 1.0% 0.5%
SETUP RISE TIME 2500ms, 80ms at full load 230VAC /115VAC
HOLD UP TIME 15ms at full load 230VAC / 115VAC









INPUT

VOLTAGE RANGE 90 ~ 305VAC 127 ~ 431VDC
FREQUENCY 47 ~ 63Hz
POWER FACTOR PF 0.95/230VAC PF 0.98/115VAC at full load and rated output voltage PF 0.9 at 50 ~ 100% load
EFFICIENCY 92% 92% 93% 94%
AC CURRENT 4A / 115VAC 2A / 230VAC 1.8A / 277VAC
INRUSH CURRENT COLD START 75A/230VAC
LEAKAGE CURRENT <0.75mA / 277VAC m



OTHERS

MTBF Khrs min. MIL-HDBK-217F
DIMENSION 252*90*42mm (L*W*H)(HLG-320H-Blank/A/B) 256*90*42mm (L*W*H)(HLG-320H-C)
PACKING Kg



Genuine MEANWELL 240W Single Output LED Power Supply HLG-240H-36

Why Choose Us ???



Original MEANWELL brand

1. We sell 100% original real MEANWELL brand, and have the certificate of UL, CUL, CE, CB, RoHS etc.

2.The different S/N code on surface of the products, can check the code with MEANWELL company.



Competitive Price +A Fast Delivery + Satisfied Customer Service

1. Our goal is to provide you the right product and make you satisfied, so please don’t hesitate to contact us via Tel or mail.

2. We shall find for you the cheapest shipping term and show you the freight and shipping time. Regarding to the urgent order, a quickest shipping term and freight will be advised to you for consideration.

3. The stock info will be informed before your order, to make everything under control.

4. We will quote to you competitive prices according to your quantities.

5. Price could be negotiated for more and large quantity.

6. We have a technical team, if you show us your LED information, we can find right drivers for you to match LED.



Shipping & Duties

Usually, shipping will be arranged within 2-3 Days upon payment or deposit, from Monday to Saturday only.



Payment

To assure you the maximum comfort and satisfaction, Currently, you can pay via T/T, L/C, WESTERN UNION, PAYPAL, More payment options will be added in the near future.



After-sale service

All of the products we sell are with a certain time warranty.

during the warranty, anything wrong with it, like no working an unstable output voltage or current, damaged, my corporation will be responsible to fix it well for free and re-send it to the clients, But, the delivery cost should be paid by purchaser himself.

We will be very glad to provide the assistance during your installation and application at any time.



Contact Us

Your inquiry and mail will be quickly responded. Suppose you have no ideas on choosing the right power supply, please do not hesitate to contact us.



We will always be here and try our best to provide you our best service !

Waiting for your kind inquiry !
